Chapter 4: Audio Connections 19
Mic/Line/DI Preamp Outputs
C|24 Mic/Line/DI preamplifier outputs appear
in two groups of 8 line-level outputs (1-8, 9-16)
on the back panel. Each group of outputs has a
DB-25 female connector, labeled as follows:
•Line Out 1-8
• Line Out 9-16
Mic/Line/DI preamplifier outputs are shown in
the following tables.
Line Outputs
Line In 9-16
Channel Signal
1 Line In 9
2 Line In 10
3 Line In 11
4 Line In 12
5 Line In 13
6 Line In 14
7 Line In 15
8 Line In 16
DI In 9-10 (overrides Mic/Line In)
Channel Signal
1DI In 9
2DI In 10
Line Out 1-8
Channel Signal
1Line Out 1
2Line Out 2
3Line Out 3
4Line Out 4
5Line Out 5
6Line Out 6
7Line Out 7
8Line Out 8
Line Out 9-16
Channel Signal
1Line Out 9
2Line Out 10
3Line Out 11
4Line Out 12
5Line Out 13
6Line Out 14
7Line Out 15
8Line Out 16
