Chapter 4: Audio Connections 23
Cue Outputs (Cue + SLS +TB)
Cue Outputs Connect the Cue Outputs to the in-
puts of your cue system.
Studio LS Outputs Connect Studio LS Outputs to
speakers in your control room.
Talkback Slate Output Connect the Talkback
Slate Output to an available Pro Tools input to
record slate information.
Listen and Talkback Microphones
C|24 provides connectors for a Listen micro-
phone and an optional External Talkback micro-
phone.
Listen Mic This XLR connector lets you connect
a microphone to provide two-way communica-
tion between the studio and the control room.
External Talkback Mic This XLR connector lets
you connect an external microphone to use in
place of the built-in Talkback microphone. Talk-
back input is selected in the Talkback Prefer-
ences in Utility mode. See “External Talkback
Microphone” on page 112.
Headphone Output
C|24 provides a headphone output with a 1/4-
inch TRS connector on the front of the unit.
Headphone source is switchable between Con-
trol Room outputs L and R (channels 1 and 3,
pre-fader) and the Cue send (post-fader).
Cue Outputs (Cue + SLS + TB)
Channel Signal
1 Cue Out Left
2 Cue Out Right
3 Studio LS Out Left
4 Studio LS Out Right
5 Talkback Slate Out
6 (Unused)
7 (Unused)
8 (Unused)
