Digigram PCX22v2 - Layout PCX924 & PCX924-MIC; Layout PCX22

PCX924 v2 , PCX924-Mic & PCX22 v2
User’s Manual
Layout PCX924 v2 & PCX924-Mic
Daughter board
on PCX924-Mic
J 2
J 1
J 3
J 5
Switch position
Up = OFF (open)
Down = ON (closed)
OFF
ON
SW1
J 4
SW2
PCX924v2
PCX924-Mic
Layout PCX22 v2
J 2
J 1
J 3
PCX22 v2
SW2
J 5
Switch position
Up = OFF (open)
Down = ON (closed)
OFF
ON
19
