D i g i g r a m
CONTENTS OF THIS PACKAGE
Thank you for purchasing a Digigram PCX924 or PCX22
v2 card.
The package consists of the following components:
* a PCX924
v2, PCX924-Mic, or PCX22v2 sound card,
* the User’s Manual at hand.
The cables (optional) are delivered separately.
FEATURES
PCX924
v2, PCX924-Mic, and PCX22v2 are audio cards for PCI bus. They are
‘Universal PCI 32-bit/33 MHz’, which means they can be plugged in 5 V PCI
slots as well as in 3.3 V keyed PCI slots. The cards are also compatible with
PCI-X interfaces.
Main hardware features
PCX924 v2 and PCX924-Mic
• 2 balanced analog mono line inputs, with:
- Software programmable analog and digital gain
- Input impedance selection (600 Ω, >10 KΩ) via switches on the card
(see top cover of the card)
• 2 servo-balanced
∗
analog mono line outputs, with software
programmable analog and digital gain
• 1 digital AES/EBU
∗∗
stereo input, for synchronization
• 1 digital AES/EBU
∗∗
stereo input, for digital data only
These two AES/EBU inputs allow:
- recording of a digital signal on the AES/EBU synchronization input
- recording of a digital signal on the AES/EBU data input, synchronized
on a digital clock connected to the AES/EBU synchronization input.
- synchronization of analog record/playback on an AES/EBU clock
The selection of the digital input for recording excludes the selection of
the analog inputs.
• 1 digital AES/EBU
∗∗
stereo output
Always plays the digital version of the analog outputs 1 and 2.
∗
Electronically servo-balanced outputs provide automatic level adjustment to accommodate
either balanced or unbalanced lines
∗∗
can be used as S/PDIF interface as well
6
