PCX924 v2 , PCX924-Mic & PCX22 v2
User’s Manual
PCX924-Mic CABLE PINOUT
Pin # ANALOG DIGITAL
1 R OUT + GPI OUT 1A
2 GND AES/EBU IN 2-
3 L OUT - AES/EBU IN 2+
4 GND AES/EBU SYNC IN 1-
5 MIC IN – AES/EBU SYNC IN 1+
6 R IN - GPI INPUT 2
7 L IN + GND/GPI INPUT COMMON
8 GND GPI INPUT 1
9 R OUT - GND
10 L OUT + LTC IN
11 GND GPI OUT 1B
12 MIC IN + GPI OUT 2A
13 R IN + GPI OUT 2B
14 GND AES/EBU OUT +
15 L IN - AES/EBU OUT -
PCX924 v2 CABLE PINOUT
Pin # ANALOG DIGITAL
1 R OUT + GPI OUT 1A
2 GND AES/EBU IN 2-
3 L OUT - AES/EBU IN 2+
4 GND AES/EBU SYNC IN 1-
5 NC AES/EBU SYNC IN 1+
6 R IN - GPI INPUT 2
7 L IN + GND/GPI INPUT COMMON
8 GND GPI INPUT 1
9 R OUT - GND
10 L OUT + LTC IN
11 GND GPI OUT 1B
12 NC GPI OUT 2A
13 R IN + GPI OUT 2B
14 GND AES/EBU OUT +
15 L IN - AES/EBU OUT -
