PCX924 v2 , PCX924-Mic & PCX22 v2
User’s Manual
• 1 CD-ROM input
• 1 SMPTE-LTC (longitudinal time code) input
• Variable programmable sampling clock, from 8 kHz to 50 kHz .
• 1 mini jack headphone stereo output
(This output is in parallel of the analog outputs 1 and 2)
• 2 General Purpose inputs and 2 outputs (GPIOs)
• Inter-card synchronization connector
If this connector is not used, synchro switches must be ON.
If it is used, one of the connected cards must have the synchro switches
ON, all the other linked cards must have the switches OFF.
PCX924-Mic additional hardware features
• 1 microphone input with switchable 48 V phantom power, and analog
expander/compressor/limiter
This input and the line input are mixed together before analog to digital
conversion.
PCX22 v2
• 2 servo-balanced
∗
analog mono line outputs, with software
programmable analog and digital gain
• 1 digital AES/EBU
∗∗
synchronization input
• 1 digital AES/EBU
∗∗
stereo output
(Always plays the digital version of the analog outputs 1 and 2)
• 1 mini jack headphone stereo output
(This output is in parallel of the analog outputs 1 and 2)
• 2 General Purpose inputs and 2 outputs (GPIOs)
• Inter-card synchronization connector
If this connector is not used, synchro switches must be ON.
If it is used, one of the connected cards must have the synchro switches
ON, all the other linked cards must have the switches OFF.
Main software features
PCX924 v2 and PCX924-Mic
• Decoding and mixing of several PCM (8, 16 and 24 bits) and MPEG
Audio streams (Layer 1, II & III)
• Real-time, simultaneous record and playback in PCM (8, 16 and 24 bits)
as well as in MPEG Audio layer I and layer II
∗
Electronically servo-balanced outputs provide automatic level adjustment to accommodate
either balanced or unbalanced lines
∗∗
can be used as S/PDIF interface as well
7
