Figure A - Menu Navigation
Start-up
Screen
FUNCTION MENU
Vacuum Level
FUNCTION MENU
Pulsator Ratio
FUNCTION MENU
M/R Ratio
FUNCTION MENU
Utility Menu
FUNCTION MENU
Pulsation Electronic
VACUUM LEVEL
Ave 0.00 “Hg
Max 0.00 “Hg
Min 0.00 “Hg
Fluc 0.00 / 1s
Enter*
PULSATOR RATIO
A+B 60.2% 699ms
C+D 39.8% 463ms
B Fluc 0.43”Hg
Max/P 10.63”Hg
Min/P 0.00”Hg
A 5.3% 61 ms
B 54.9% 638 ms
C 5.7% 66 ms
D 34.1% 397
ms
Total 1162
-OPTION MENU
Function Menu
Hold
Reset (Only for Vacuum Level
Function)
Store
Store Graph (not for Pulsation
Electronic)
Recall
Print/Upload
Limping data (Only for
Pulsator Ratio Function)
Enter
Back to
Function
Menu
Enter
Back to
Function in Hold
Enter
Back to
Function
Enter
Menu
*
M/R RATIO
Ratio 63:37
PPM 54.2
Max/P 13.59 “Hg
Min/P 0.02 “Hg
Milk 63.3 %
Milk 701 ms
Rest 36.7 %
Rest 405 ms
LCP 6.50 “Hg
TTime 1106
PULSATION ELEC 01
On 60.4%
Off 39.6%
Max/P 10.2 Volts
Min/P 0.0 Volts
PPM 60.4
* Use Up & Down
Arrow Keys
-UTILITY MENU
1Upload-Print all
Data
2 Upload Graphic
Data
3 Print Graph
4 Fluc. Time
Frame >1 2 3 4
5 10 sec
5 Liner Collapse
Point Equals
LCP= 6.5 “Hg
6 Type Pulsation
>Dual
Single
7 Units
>Inches Hg
kPa
8 Auto Shutoff
30 minutes
9 Clear
Storage
Memory
10 Print limping
data
11 Set Pulsator
Limits
Press Enter to
start graphing
Menu to exit.
RECALL 09:06:14
> 01 BARN #1
02 MILK TRAP
03 08:12:00
Send Slot 01
BARN #1
Enter to send
Menu to exit.
Back to
Function
Menu - back to
Option Menu
To Printer or
Computer then back
to Option Menu
Enter
Enter
Enter
Enter for 3
sec. of graph
Up/Down changes.
Menu to exit.
STORE 09:06:14
01 BARN #1
02 MILK TRAP
03 08:12:00
> 04
Label Slot 09
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Menu to Save.
Enter
Save then To
Option Menu
Menu
PRINT 09:06:14
> 01 BARN #1
02 MILK TRAP
03 08:12:00
Enter
Menu
Back to
Option
Menu
Enter
(Enter to move cursor)
Enter
Enter
Menu
Enter
Enter
Enter
Enter
GRAPH
09:06:14
> M01 BARN #2
V02 MILK TR
P03 08:12:15
GRAPH 01:16:58
> 01 BARN
02 MILK
03
Label Graph 01
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Menu to Save.
Back to function in record mode
Menu to
Exit
Menu
Menu
Menu
Enter
LIMPING
> View one
item
LIMPING
> 01AB Available
02AB Not Avail.
03AB Not Avail.
LIMPING
01AB Limping
0.2 %
1 msec
LIMPING
02AB Not Avail.
(press the down arrow
key for more items)
Set Limits:
Bfluct Max 0-3.00
MaxHiV/Pls 5.5-
16.00
MinHiV/Pls 5.0-15.50
MinVac/Pls 0-4.00
MaxAPhase 20-300
MinAPhase 20-300
MaxBPhase 100-750
MinBPhase 100-750
MaxCPhase 20-500
MinCPhase 20-500
MaxDPhase 100-500
MinDPhase 100-500
Max PPM 20-198
