Graphs & Printouts
The following pages will examine the
different printouts that can be printed
with the Digimet 3000 and the Digimet
Printer. Refer to other parts of this
manual for information on printer
operations and correct hook-up to the
Digimet 3000.
Printed material can be obtained by
using the commands listed below:
From each of the function’s Option
Menu, the Print/Upload command will
print numeric data for each item stored
similar to Recalling an item and viewing
it on the Digimet 3000 display. The data
listed below is a representation of the
information that would print from a stored
Vacuum Level item:
VACUUM LEVEL
Barn #1 at trap
Location Timer
01 01:52:47
Ave 12.01 “Hg
Max 12.03 “Hg
Min 11.99 “Hg
Fluc 0.04/ 1 sec period
All numeric printouts will have a similar
format.
Function
Label (up to 16 characters)
Location refers to slot storage number
Timer stamp
Ave, Max Min and Fluc data
Fluctuation time frame
