33
Use this feature to obtain the most
desirable printout.
File - Print
The following are print options to the
printer attached to your computer:
Print Vacuum Level Data in either a
standard or grid format. Print Pulsation
Electronic data. Print Pulsator Ratio data
in dual or single display mode. The dual
print will include comparisons of the two
chambers of the dual pulsator. Print the
Milk/Rest ratio data in grid format. The
next to last print option is Print Graph. This
will print the graph that is displayed with
Display Graph. The Start time of the
printed graphs is indicated at the left
corner of the graph. The graph increments
is also indicated at the bottom of the
graph. Graph increments are 250
milliseconds. A graph printout is shown on
page 47. The last Print option is Print
Limping Data and consists of the Limping
data calculations.
File - Exit
Exit the DigiData program. A warning
window will appear recommending that the
numeric data be saved to a file.
Options - Label Data Set
Label data file with up to 16 characters.
Options - Set Com Port
Com port 1, 2 , 3 or 4 can be used to
upload data from the Digimet. If the wrong
Com port is set or the one chosen is
presently in use by some other device, like
the mouse, the program will exit if you
press the Upload Item, Upload All, Upload
Graph, Rec. archive data command
buttons. This is the Com port that you will
use to connect the Digimet to the
computer.
Options - Type Pulsation
This option only effects the Pulsator Ratio
and the M/R ration functions. In the Dual
mode the items are labeled 1A-1B etc., in
the single mode the items are labeled 1, 2,
3 etc. when viewing the standard viewing
mode. In grid viewing mode, in single
mode the items are listed one after the
other. In the Dual mode, each two items
are compared.
Options - Graphing
This allows you to set the following options
for graphs 1) Minimum and Maximum lines
will appear on the graphs, 2) the number
of Y axis ticks can be chosen and 3)
vertical grid lines can be used.
Options – Set Pulsator Limits
Refer to page 27 of this manual for
information about setting pulsator limits.
Same limits can be set in the Digidata
program as in the Digimet 3000 Version
4.0 unit. In the Digidata program the terms
Max. Vac / P - Maximum and Max. Vac / P
– Minimum are referring to the terms
MaxHiV/Pls and MinHiV/Pls in the Digimet
3000. All other terms are the same as
appear in the Digimet 3000 Utility Menu –
Set Pulsator Limits.
Options – View Pulsator Limits
This will show the limits that have been set
for the corresponding pulsator parameter.
View Grid or Standard
Grid view or standard view are the
choices.
View Inches Hg or kPa # IMPORTANT #
When measurement units are set to
inches of Hg or set to kPa in the
