32
loaded into your computer by running the
Setup program. This section will outline all
the functions of the program.
Click on the Digimet icon to run the
program.
To view data, open a file that has been
previously uploaded and saved or upload
data by using the commands at the right
hand side of the display.
Upload Item
From the Digimet screen in any of the four
functions, choose Print/Upload. Select the
item by choosing your labeled or timer-
stamped item. The next screen will
indicate that after pushing the Enter key
you will send data to the Digimet. BUT,
before taking that last step, put the
computer program into the Upload mode,
to accept the data from the Digimet, by
clicking the Upload Item command in the
upper right corner of the screen. At this
point, the command button on the
computer will have changed to Done
Upload Item and will be highlighted in red.
Now, press the Enter key on the Digimet.
As soon as the option screen appears on
the Digimet this is the signal that the
Digimet has completed the send. Now, on
the computer screen, click the Done
Upload Item. This will place the data in the
computer and in the appropriate function
screen. See section on CABLES in order
to properly hook the Digimet to the
computer.
Viewing Data
The Digimet data can be viewed in either a
standard format or grid format. This choice
is made in the Menu item, VIEW. In the
Standard Mode, the number of the Tab will
be red if there is data in the storage item.
You can use the mouse or arrow keys to
move to different tabs.
Notes
The window below the main window in the
Standard Mode is used for notes referring
to the item chosen. Notes only appear in
the Standard viewing mode. Notes will
appear on the print-outs. In the dual
pulsation storage mode, only one set of
notes is available for a dual chamber
pulsator.
MENU
File - New
Start a new file.
File - Open
Open files that contain data that has been
previously uploaded from the Digimet. The
files end with .dm3. Only that type of file
(.dm3) will be retrieved into the digidata
program for display of numeric data.
File - Save As
Files that can be saved have a .dm3
ending. When saving numeric data, the file
must end with .dm3. The Save BMP
command saves a bitmap graphic picture
of the graphs that are displayed in this
program. One note, they are big files
approximately 250k bytes.
It is not necessary to save graph files as
BMP files. This would only be necessary if
you wished to save graphs to view in other
programs. The .dgr graph files, which can
be viewed by the DigiData.exe program
are redisplayed each time from the original
data .dgr files. Also, to save a file as
a .BMP, you must be viewing a graph file
on the computer screen with the Display
Graph command.
File – Set Printer Font
