24
Flanger Knob 2
(Pre/Post
Amp)
Knob 3
(Speed)
Knob 4
(Depth)
Knob 5
(Regenera-
tion)
Knob 6
(FX Level)
flanger
Pre/Post Amp Speed Depth Regen Level
trigflng
Pre/Post Amp Speed Sensitivity LFO Start Level
fltrflng
Pre/Post Amp Speed Depth Regen Frequency
mx flngr
Pre/Post Amp Speed Width Regen Manual
EH flngr
Pre/Post Amp Rate Range Color --
AD flngr
Pre/Post Amp Speed Enhance Range Manual
Phaser
A phaser splits the incoming signal, and then changes the phasing of the signal. This signal is then
taken in and out of phase and mixed back in with the original signal. As the phasing changes, dif-
ferent frequencies get canceled resulting in a warm sort of twisting sound. The RP1000 includes
the following Phaser types: phaser (the DigiTech Phaser), trigphas (the DigiTech Triggered
Phaser), mx phasr (based on an MXR Phase 100), and eh phasr (based on an Electro-Har-
monix Small Stone).
Knobs 2-6 have the following functions for the various Phaser Effects:
Phaser Knob 2
(Pre/Post
Amp)
Knob 3
(Speed)
Knob 4
(Depth)
Knob 5
(Regenera-
tion)
Knob 6
(FX Level)
Phaser
Pre/Post Amp Speed Depth Regen Level
trigphas
Pre/Post Amp Speed Sensitivity LFO Start Level
mx phasr
Pre/Post Amp Speed Intensity -- --
eh phasr
Pre/Post Amp Rate -- Color --
Vibrato (viBRaTo)
The DigiTech Vibrato effect modulates the pitch of the incoming signal at an even rate.
Pre/Post Amp - Knob 2 determines where the effect appears in the effects chain. Turn
counter-clockwise for Pre (appears before the Distortion effect), or clockwise for Post
(appears after the Noise Gate effect).
Speed - Knob 3 adjusts the rate (Speed) at which the pitch modulates. Ranges from 0 to
99.
Depth - Knob 4 adjusts the intensity (Depth) of the modulating pitch. Ranges from 0 to
99.
Rotary Speaker (ROTARY)
The Rotary Speaker emulates a device that included a spinning horn and woofer. The rotation of
these two speakers produced an interesting combination of the sound panning from side to side.
