Dimplex A12M User Manual

6
 Products not installed with the
Dimplex hydraulics packs will not be
supported by Dimplex. This includes
but is not limited to thermal stores.
 During the commissioning of the
domestic hot water cylinder, ensure
that the cylinder is full and no water
is drawn from the cylinder as this
will adversely affect the heat pumps
operation.
 This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance in a
safe way and understand the
hazards involved. Children shall not
play with the appliance. Cleaning
and user maintenance shall not be
made by children without
supervision.
3.2 Intended use
This device is only intended for
domestic use, as specified by the
manufacturer. Any other use beyond
that intended by the manufacturer is
prohibited. This requires the user to
abide by the manufacturers product
information. Please refrain from
tampering with or altering the device.
3.3 Legal
The construction and design of the heat
pump complies with all relevant EU
directives (see CE declaration of
conformity).
When connecting the heat pump to the
power supply, the relevant EN and IEC
standards are to be adhered to. Any
further connection requirements
stipulated by the network operation
must also be observed.
When connecting to the heating system
all applicable regulations must also be
adhered to.
3.4 Heat pump sizing
 Ensure that the correct size heat
pump has been selected in
accordance with the latest version of
MIS3005 (UK only) and with the
Dimplex Heat Pump Planning
Manual.
 If a non A-Class heat pump cylinder
is being used, ensure that it has
been accurately sized with the
appropriate coil surface area of the
cylinder to match the heat pump’s
output, flow rate requirements and
that all necessary hydraulic
connections have been considered in
connecting it to the heat pump
system.
 Ensure that suitable heat emitters
have been sized in accordance with
the Heat Emitter Guide (UK only)
and selected ensuring a low flow
temperature design. To maximise
system efficiency it is important to
design the system with the lowest
flow temperature possible.
3.5 Site selection
3.5.1 Location of heat pump
 The heat pump must be installed
outdoors with adequate clearances
for ventilation and maintenance as
shown in figure 2. It is
recommended that the heat pump is
installed along the property wall, as
shown below.
 There must be a minimum distance
of 1000mm in front of the fan to
