Dimplex A12M User Manual

24
10 Technical Specifications
1
Type and order code
A 12
A16
2
Design
2.1
Degree of protection according to EN 60529 for compact unit or heating element
IP 24
IP 24
2.2
Installation location
Outdoors
Outdoors
3
Performance data
3.1
Operating temperature limits:
Min / Max
Min / Max
Heating water flow and return temperature
°C
25 / 65
25 / 65
Outside air temperature
°C
-20 / 35
-20 / 35
Seasonal Performance Factor (SPF) for Under floor at 35°C
1
3.9
3.9
Seasonal Performance Factor (SPF) for Radiators at 55°C
1
3.6
3.6
3.2
Heating water temperature difference at standard rating
condition
A7 W35
2
K
5
5
Heat output / COP
at A7 W35
2
kW / ---
12 / 4.7
12 / 4.7 *
at A-2 W35
2
kW / ---
12 / 3.5
15.5 / 3.2
at A-7 W35
2
kW / ---
12 / 3
14.3 / 3
at A7 W55
2
kW / ---
12 / 3
12 / 3 *
at A-2 W55
2
kW / ---
12 / 2.5
15.6 / 2.4
at A-7 W55
2
kW / ---
12 / 2.2
15.3 / 2.2
at A7 W65
2
kW / ---
12 / 2.5
12 / 2.5*
at A-2 W65
2
kW / ---
12 / 2.0
15 / 1.99
at A-7 W65
2
kW / ---
12 / 1.8
15 / 1.8
* Performance at this point is optimised to match the building heat load and maximise the Seasonal performance factor.
3.3
Sound power level
3
(Provisional)
dB(A)
64
64
3.4
Sound pressure level at 10m (Heat pump against wall)
dB(A)
40
40
3.5
Heating water flow rate @ A7 W35 (nominal)
m³/h, l/min
2.1 / 35
2.1 / 35
3.6
Air flow @ A7 W35
m³/h
3700
3700
3.7
Refrigerant; total filling weight
Type / kg
R410A / 2.0
R410A / 2.0
3.8
Water capacity of stainless steel heat exchanger
litre
1
1
3.9
Polyol ester oil in compressor
litre
1.18
1.18
4
Dimensions, connections and weight
4.1
Device dimensions without connections
H x W x L mm
1571 x 932 x 401
1571 x 932 x 401
4.2
Physical volume
m³
0.59
0.59
4.3
Device connections to heating system
inch
1" ext. thread
1" ext. thread
4.4
Weight of the transportable unit(s) excluding packaging
kg
130
130
5
Electrical connection (Heat pump)
5.1
Nominal voltage; fuse protection
V / A
230 / C 40
230 / C 40
5.2
Nominal power consumption / current A7 W35
kW / A
2.6 / 11
2.6 / 11
5.3
Maximum power consumption / current A-2 W65
kW / A
6.9 / 30
8.1 / 35
5.4
Power factor A7 W35 / cosϕ
A / ---
11 / >0.95
11 / >0.95
5.5
Power input of integral fan @ A7 W35
4
W
60
60
6
Other design characteristics
6.1
Defrosting
Automatic
Automatic
Type of defrosting
Reverse cycle
Reverse cycle
6.2
Heating water in device protected against freezing by software
Yes
Yes
1.)
Calculated to EN15316 excluding hot water
2.)
These data characterise the size and performance of the system according to EN 14511 with clean heat exchangers. Abbreviations have
the following meaning, e.g. A2 / W35: outside temperature 2°C and heating water supply temperature 35°C. A2 / W35 test, takes into
account defrosting as per EN 14511.
3.)
According to EN 12102.
4.)
Fan is variable speed, rated input relates to nominal input power.
