9
Disconnect power before attempting any
maintenance or cleaning to reduce the risk of re, electric
shock or damage to persons.
Allow at least ve (5) minutes for light bulbs to cool before
touching bulbs to avoid accidental burning of skin.
Light bulbs need to be replaced when you notice a dark
section of the ame or when the clarity and detail of the log
ember bed exterior disappears. There are four (4) bulbs
under the log set, which generate the ames and embers,
and two (2) bulbs above the log that illuminate the log
exterior.
Quantity of four (4) clear chandelier or candelabra bulbs with
an E-12 (small) socket base, 60 Watt rating. Example: GE
60BC or Philips 60 CTC.
It is a good idea to replace all light bulbs at
one time if they are close to the end of their rated life. Group
replacement will reduce the number of times you need to
open the unit to replace light bulbs. Care must be taken
when removing the Log Set as the Log Set contains LED’s
and wires.
Open the Bi-fold doors.1.
Pull the front edge of the plastic Ember Bed or plastic 2.
grate up and forward until the rear tab releases from the
ledge located at the bottom of the Partially Reective
Glass.
!
Only handle the Log Set by the Ember Bed.
!
Log Set ts tightly into rebox. Some force may
be necessary to remove.
Set Log Set in front of rebox.3.
Disconnect the Log Set LED wire harness from unit.4.
Lift the left side of the icker rod out of the mounting 5.
bracket.
Examine the bulbs to determine which bulbs require 6.
replacement.
Unscrew bulbs counter clockwise.7.
Insert new bulbs.8.
Install the left side of the icker rod into the mounting 9.
bracket.
Reconnect the Log Set LED Wire Harness.10.
Replace the Log Set by inserting the rear tab of the 11.
Ember Bed under the Partially Reective Glass and
pushing down on the front edge of the Ember Bed until it
snaps into place (Figure 6).
!
Ensure the Log Set is installed tightly under the
back ledge to prevent light leakage.
Close the Bi-fold doors.12.
Quantity of two (2) clear chandelier or candelabra bulbs with
an E-12 (small) socket base, 25 Watt rating.
Open the Bi-fold doors.1.
Remove upper light bracket with a screwdriver (Figure 7)2.
Replace bulb.3.
Reassemble in the reverse order as above.4.
(Figure 8)
The Purire™ lter supplied in your replace is reusable
and washable. The lter should be cleaned or replaced on
average once a year.
To clean the lter, gently tap lter on a hard surface to
dislodge any loose dirt or debris, then clean with water. No
soap or cleaning products are recommended. The lter size
is 20 inches x 10 inches x 1 inch rated at MERV 10. If using
an after market lter follow the manufacturers recommended
replacement instructions.
Open the Bi-fold doors.1.
Remove the three (3) mounting screws from the Air Filter 2.
Bracket.
Remove the Air Filter Bracket assembly from the rebox.3.
Slide Filter out of Air Filter Bracket.4.
Replace lter and reassemble in reverse order as above.5.
!
If after market air lter is used ensure it is
installed according to the manufacturer’s recommended
instructions.
The glass is cleaned in the factory during the assembly
operation. During shipment, installation, handling, etc., the
glass may collect dust particles, these can be removed by
dusting lightly with a clean, dry cloth.
To remove ngerprints or other marks, the glass can be
cleaned with a damp cloth. To prevent scratching, do not use
abrasive cleaners or spray liquids on the glass surface.
Use a cloth dampened with warm water only to clean painted
surfaces of the electric replace. Do not use abrasive
cleaners.
Air Filter
Bracket
Mounting
Screws
