Edel Air Source Water Heater - Product Features
Materials
Inner cylinder Stainless steel
Outer cylinder Plastic
Inlet/outlet Stainless steel
Insulation 50mm PU foam (GWP=1, ODP=0)
Maximum Operating Conditions
Potable water temperature 65°C via immersion, 55°C via compressor alone
Operating pressure 3 bar
Maximum design pressure 6 bar
Heat Pump max. pressure 25 bar
Cold Water Supply
Minimum dynamic pressure 1.5 bar
Maximum pressure 12 bar
15 l/min
Connections
Cold water inlet M 3/4” stainless steel
Hot water outlet M 3/4” stainless steel
Air pipe diameter
(inlet and outlet)
Insulated 80/125 concentric ducting
Immersion Heater
1.2 kW@240V
Ventilation
90 to 140 m
3
/h
Air temperature -7°C to 35°C
Max. air pipe length Rigid piping: Refer to section 6.7 ductwork calculation
0.3 L/h
Condensates drainage pipe 18/23 mm
Safety Components
Pressure reducing valve and
strainer
3 bar
Expansion relief valve 6 bar
Temperature and pressure
relief valve
7 bar/90°C 1/2” BSP
Factory pressure test 12 bar
Integrated electrical back-up
power
1200W (safety setting = 84°C)
Approvals
KIWA approval number - 1701712
Guarantee
Inner cylinder 5 years
Immersion heaters
Other components 2 years - excluding expansion vessel membrane pressure
Table 10: Edel Air Source Water Heater Product
Technical Data and Product Fiche
