This Commissioning Checklist is to be completed in full by the competent person who commissioned the storage system as a means of demonstrating
compliance with the appropriate Building Regulations and then handed to the customer to keep for future
reference.
Failure to install and commission this equipment to the manufacturer's instructions will invalidate the warranty, but does no
t affect statutory rights.
Customer
Name Telephone Number
Address
Cylinder Make and Mode
l
Cylinder Serial Number
Commissioned by (
print name) Registered Operative ID Number
Company Name
Telephone Number
ALL SYSTEMS
What is the incoming static cold water pressure at the inlet to the system
? psi
Has a strainer been cleaned of installation debris (i
f fitted)? Yes No
Is the installation in a hard water area (abov
e 200ppm)? Yes No
If yes, has a water scale red
ucer been fitted? Yes No
What type of scale reducer has been fitted?
What is the hot wa
ter thermostat set temperature? °C
What is the maximum hot water flow rate at set thermostat tem
perature (measured at high flow outlet)? l/min
Time and temperature controls have been fitted according to CSA Sta
ndards and local codes? Yes
What is the hot water tem
perature at the nearest outlet? °C
All appropriate pipes have been insulated up to 1 metre or the point where they become concealed
Yes
UNVENTED SYSTEMS ONLY
Where is the pressure reducing v
alve situated (if fitted)?
What is the pressure reducing valve
setting? psi
Has a combined temperature and pressure relief valve and expansion valve been fitted and discharge tested? Yes No_________
The tundish and discharge pipework have been connected and ter
minated according to CSA Standards and local codes? Yes
Are all energy devices fitted wi
th a cut out device? Yes No
ALL INSTALLATIONS
The hot water system complies with the appropriate CSA standards
and local codes Yes
The system has been installed and commissioned in accordance with the manufacturer's instructions
Yes
The system controls have been demonstrated to and understood by the customer
Yes
The manufacturer's literature, including this Checklist and Service Record, has been explained and left with the customer
Yes
MAINS PRESSURE HOT WATER STORAGE SYSTEM COMMISSIONING CHECKLIST
Commissioning Engineer's Signature
Customer's Signature
(To confirm satisfactory demonstration and receipt of manufacturer's literature)
