13. The third row of energy cells is positioned in a manner similar to the first row. Again
be careful not to damage or dislodge the element. (Fig. 13)
14. Fit the fourth row of energy cells above the third row in the upside position. Again,
the first energy cell should be positioned firmly against the right-hand insulation, and
the second energy cell should be positioned firmly against the left-hand insulation.
(Fig. 14). Repeat for the fifth and sixth rows of energy cells built around the third
element to complete the core build.
15. Remember the top row of energy cells must be fitted upside down. (Fig. 15)
Check that all the energy cells are secure and evenly located.
16. Close the core by refitting the inner front panel complete with insulation, starting at
position ‘U’ and working clockwise. (Fig. 16)
Ensure the bottom tabs are located inside the chassis and that the screws are tightly
secured down each edge.
Ensure the screws retaining the heater to the wall are fully tightened, once the energy
retention cells are fully loaded. (Fig. 6)
IMPORTANT
Double check all mains connections are secure and excess cable is restrained
and not in contact with any of the heater casing.
ON NO ACCOUNT SHOULD ANY SURPLUS CABLE BE PUSHED INSIDE OR BEHIND
THE HEATER.
Once installed DO NOT attempt to reposition the heater without first unloading the
energy cells.
Reassembly
To replace the bottom grille and front panel, reverse steps 3 and 4 of these instructions
under the section headed Preparation.
Inspect the grille guard for damage before refitting the lower grille to the heater.
Ensure all fixings are secure.
