The heater must be securely fixed to a wall. Screws with suitable wall fixings for solid
walls are provided. If other wall types are encountered it is the installer who must
choose the most suitable fixing.
SUGGESTED FIXINGS
SOLID BRICK/BLOCK: No. 10 size high temperature resistant plastic inserts, 8mm drill
bit. Drill hole 15mm deeper than plastic insert length.
PLASTERBOARD - If possible locate studding and use No. 10 woodscrews directly
into the wood, otherwise M5 rawlplug intersets are suitable.
NOTE: FOR OTHER WALL TYPES (eg. timber frame and hollow concrete) SEEK
SPECIALIST ADVICE.
If the floor is carpeted then the carpet should be slit and underlay cut away to allow
the feet to rest firmly on the floor. Carpet gripper must be locally removed so that the
feet may rest in a level position.
This appliance is heavy. The floor must be checked to ensure that it is capable of
bearing the weight of the unit, up to 165kg.
This Heater is rated IPX4
DO NOT UNDER ANY CIRCUMSTANCES ATTEMPT TO MOVE OR REPOSITION
THIS HEATER WITHOUT SEEKING EXPERT ADVICE. THE HEATER SHOULD
NEVER BE FREED FROM THE WALL WITH ENERGY CELLS INSIDE.
USE CAUTION WHEN INSTALLING THIS PRODUCT, UNPAINTED METALWORK
CAN HAVE SHARP EDGES.
IMPORTANT Head of wall fixing screw must be flanged pan head type and have a
diameter no less than 11mm. No countersunk headed screws to be used for wall fixing.
Installing the Heater
Fig. 4 Fig. 5
8
