Schaltplan - XLE Serie A
ZEIGT WEISSEN DRAHT ZEIGT SCHWARZEN
DRAHT
NIEDRIGER
LINKER STATUS
(130 ° BLAU)
NIEDRIGER
RECHTER STATUS
(130 ° BLAU)
RAUMTHERMIS-
TOR
AN HAUPTREG-
LERMODUL
ANGEBRACHT
BOOST-GRENZE
STAT. (120 ° GRÜN)
MANUELLE
AUSSPARUNG (140 °)
BENUTZEROBERFLÄCHE
ERDUNG
ERDUNG
ERDUNG
NEUTRAL
(HAUPTZEITEN)
LIVE
(HAUPTZEITEN)
LIVE
(NEBENZEITEN)
NEUTRAL
(NEBENZEITEN)
BELÜFTUNG
PCB
GRENZSTAT.
(125 ° SCHWARZ)
KERNTHERMISTOR
AUF DER INNENSEITE MONTIERT
(PLASTIKGEHÄUSE)
LAGERELEMENTE
