Specifications
Power Requirements 6 AA Alkaline, Ni-Cad or NiMH batteries (not included)
OR an optional 100 to 240 VAC 50/60Hz 12 VDC 1A
wall plug-in UL/CSA listed AC power adapter
Operating Temperature 14 to 104ºF (-10 to +40ºC)
Display 6 digit, 7 segment
0.7" high LCD
Sensitivity 0 to 2.4 mV/V
Signal Input Range 0 to 12 mV max.
Transducer Excitation 5.0 VDC
Resolution 2,500 divisions
Capacities Chair: 400 x 0.2 lb. (181.4 x 0.1 kg)
Wheelchair: 800 x 0.2 lb (362.9 x 0.1 kg)
Tolerance Chair:
Applied Weight Tolerance
0 0 to 0
25 lbs. 25 lbs. to 25 lbs.
50 lbs. 50 lbs. to 50 lbs.
100 lbs. 100 lbs. to 100 lbs.
200 lbs. 199.8 lbs. to 200.2 lbs.
300 lbs. 299.6 lbs. to 300.4 lbs.
400 lbs. 399.6 lbs. to 400.4 lbs.
Wheelchair:
Applied Weight Tolerance
0 0 to 0
200 lbs. 199.2 lbs. to 200.2 lbs.
500 lbs. 499.4 lbs. to 500.6 lbs.
800 lbs. 799.0 lbs. to 802.4 lbs.
Division Value 1, 2 or 5
Sample Rate 1 to 16 samples per second
Auto Zero Range 0.5 or 1 through 9 divisions
Weighing Units Pounds, kilograms, pounds/kilograms and kilograms/
pounds
Keyboard Membrane type with 5 keys and 4 directional arrows
Enclosure Size 6
1
⁄8" W x 6
3
⁄4" H x 1
3
⁄4" D (16 cm x 17 cm x 4 cm)
Construction Painted Steel
Standard Features:
• Metric Conversion • Data transmitted wireless via Bluetooth
• Auto Shutoff Feature • Selectable Sleep Mode
• BMI Calculation • Selectable Filtering
• Weight Recall Feature
Optional Features:
• Optional 12V DC AC Power Adapter
