door lock harness wire connection guide

These door lock outputs are for Passive arming control of the factory door locks.

They can also be used to control the door locks with the ignition switch for vehicle

that do not have this feature in the factory RKE system.

___

The control module can control 2 common power door lock types without any addition-

al parts. With certain vehicles, or if an actuator is to be installed, either a 451M Door

Lock Relay Satellite or two relays will be required. Refer to TechTips document 1041.

plug-in harnesses

integrated LED/Valet

switch

The integrated LED/Valet

switch should be accessible from the driver’s seat. The

Valet

part of the integrated LED/Valet

switch plugs into the blue port on the side of

the unit. Check for rear clearance before drilling a 5/16-inch hole and mounting the

switch. The LED part of the integrated LED/Valet

switch operates at 2V DC and plugs

into the white port on the side of the unit. Make sure the LED wires are not shorted to

ground as the LED will be damaged.

data port—Bitwriter

The black three-pin port can be used for programming the unit using the Directed

Bitwriter, a hand held programming tool. The Bitwriter also allows programming of

features that are not available in the feature menus.

BLUE (-) Unlock, (+) Lock Output

Not Used

GREEN (-) Lock, (+) Unlock Output

H3/A

H3/B

H3/C

Directed Electronics AM1 Installation Guide

Other manuals for Directed Electronics AM1
