main harness wire connection guide

main harness wiring diagram

___

main harness wiring guide

HH11//11 OORRAANNGGEE ((--)) 550000 mmAA ggrroouunndd--wwhheenn--aarrmmeedd oouuttppuutt::

This wire supplies a (-)

ground as long as the system is armed. This output ceases as soon as the system is

disarmed. This wire controls operation of the pre-wired starter kill relay and can be

used to control other optional accessories.

NNOOTTEE::

If connecting the orange wire to control another module, such as a 529T or

530T window controller, a 1 amp diode (type 1N4004) will be required. Insert the

diode as shown below.

RED/WHITE (-) 200mA Auxiliary Channel/Delayed Accessory Output

RED (+) 12V Constant Power Input

BROWN (+) Siren Output

YELLOW (+) Ignition Input

BLACK (-) Chassis Ground Input

VIOLET (+) Door Trigger Input

BLUE (-) Instant Trigger (Hood and Trunk Pin)

GREEN (-) Door Trigger Input

BLACK/WHITE (-) 200mA Domelight Supervision Output

WHITE/BLUE No Function

WHITE (+)/(-) Light Flash Output

ORANGE (-) 500mA Ground When Armed

H1/1

H1/2

H1/3

H1/4

H1/5

H1/6

H1/7

H1/8

H1/9

H1/10

H1/11

H1/12
