features #1 menu
Factory default settings are shown in
bboolldd
.
Feature steps 5 and 6 are related. Only if Auxiliary Output Enabled is selected in fea-
ture 5 can either Auxiliary Output or Delayed Accessory Output be selected in fea-
ture step 6. Examples of this are where Auxiliary Output is used to provide a momen-
tary 800mSec pulse on the RED/WHITE wire of the main harness (can be used for
opening the trunk). The delayed accessory output is used to allow selected vehicle
accessories to remain on (such as radio) when the ignition is turned off. This output
will remain active for 1 hour until a door is opened and closed, or the system is armed
using the factory remote transmitter.
Feature
Step
Lock Button (one chirp) Unlock Button (two chirps)
1 Active arming Passive arming
2 Chirps ON Chirps OFF
3 Door Trigger Error Chirp ON Door Trigger Error Chirp OFF
4 Ignition-Controlled Domelight ON Ignition-Controlled Domelight OFF
5 Panic Enabled (OEM upgrade) Auxiliary Output Enabled (OEM upgrade)
6 Auxiliary Output Delayed Accessory Output
7 Delayed Door Trigger Instant Door Trigger
8 Sensor shunt zones 1, 2 & 4 All zones
9 Siren Duration–30 seconds Siren Duration–60 seconds
10 Valet
®
switch input: 1-pulse Valet
®
switch input: 2-5 pulses
11
Horn pulse honk duration 0.020
seconds (does not affect full trig-
ger pulse duration)
0.030, 0.040, 0.050 seconds
To Next Page
