47
© 2008 Directed Electronics. All rights reserved.
1-3, Horn Function: Turns On/Off the confirmation honks when locking/unlock-
ing. Use it to change the output pulse duration for vehicles that require a longer
pulse for the horn to honk. Confirmation honks ON (20mS) & panic, (1)
Confirmation honk (30mS) & panic, (2) Confirmation honk (40mS) & panic (3)
Confirmation honk (50mS) & panic (4) Confirmation honks OFF, panic only (5).
When choosing panic only; the horn will not sound when locking or unlocking,
only when the panic feature is used.
1-4 Ignition Locks Off:
(1) When turned Off the system does not lock/unlock the
doors when the ignition is turned on. (2) Lock and Unlock. The doors lock three
seconds after the vehicles doors are closed when the ignition is turned On, and
unlock when the ignition is turned Off. (3) Lock: Locks the doors three seconds
after the ignition is turned On and the vehicles doors are closed. 4) Unlock:
Unlocks the doors when the ignition is turned off.
Important:
The optional door input must be connected for
the ignition controlled lock feature to work.
1-5 Single Pulse Lock/Unlock(1):
The system sends out a single pulse when lock-
ing and unlocking. (2) Double-pulse unlock sends out 2 pulses when unlocking.
(3) Double-pulse lock sends out 2 pulses when locking. (4) Double-pulse lock/
unlock sends out 2 pulses when locking and unlocking.
1-6 0.8 sec Door Lock Pulse (1)Duration:
The default setting is 0.8 second door
lock pulses. Some European vehicles, such as Mercedes-Benz and Audi, require
longer lock and unlock pulses to operate the vacuum pump. Programming the
system to provide 3.5 second (2) pulses, accommodates the door lock interface
in these vehicles. (See door lock connections section for wiring information re-
garding Type E door locks interfacing. The 0.4 second (3) pulse is required on
some vehicles where the lock wires can also control the windows and the 0.8
second pulse causes the windows to open/close when locking or unlocking.
1-7 No 2nd Unlock Output (1):
The second unlock output is defeated at all
times. 2nd unlock On with ignition control, after first unlock turns on the 2nd un-
lock output and unlocks the passengers doors after the driver’s door is unlocked
with ignition controlled locks. (3) 2nd unlock on with ignition control with first
unlock will turn on the 2nd unlock output and will unlock the passengers doors at
the same time the driver door is unlocked with ignition controlled locks.
