11 403.VW06 1.27 2016 Volkswagen Golf (Smart Key)

Input 10-pin black connector (H3)

Module Connects To

Conn./Pin Color Description Wire Location (+/-) Wire Color Ref.

H3/1 Black/White (-) No Connection

H3/2 Green/Black (-) No Connection

H3/3 Green/White

(-)

[2]

No Connection

H3/4 Red/Black (-) No Connection

H3/5 Violet/White

(-)

[3]

No Connection

H3/6 Gray (-) Hood Switch Input

H3/7 Gray/Black (+) No Connection

H3/8 Violet/Green (+) No Connection

H3/9 Violet/Brown (+) No Connection

H3/10 Yellow/Black (-) No Connection

D2D 4-pin white connector (H4)

Module

Conn./Pin Color Description

H4/1 Green (Data) TX

H4/2 Black (-) Ground

H4/3 Blue (Data) RX

H4/4 Red (+) 12 Volt

RF 2-pin white connector (H5)

Module

Conn./Pin Color Description

H5/1 N/A

H5/2 N/A

Directed DB3 Installation Guide
