14 403.VW06 1.27 2016 Volkswagen Golf (Smart Key)
© 2017-02-08 Directed. All rights reserved.
Module programming
Refer to “LED diagnostics and troubleshooting” for more information and for troubleshooting purposes.
1
Connect the 10-pin, 12-pin and 14-pin harnesses to DB3, then wait until the LED turns
ON solid red.
2
Press the Push-to-Start (PTS) button once to turn the ignition ON. The LED flashes
orange, then flashes green.
3
The LED turns ON solid green for 3 seconds, then turns OFF.Press the PTS button
once more to turn the ignition OFF.
You have successfully completed the module programming sequence.
