10 403.VW06 1.27 2016 Volkswagen Golf (Smart Key)
© 2017-02-08 Directed. All rights reserved.
Vehicle connections
The connection information listed below is specific to the 2016 Volkswagen Golf (Smart Key). Refer to “Pre-installation and application warnings” for a list of important notes.
Data 14-pin blue connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Ref.
H1/1 Light Green (DATA) No Connection
H1/2 Violet/Yellow (DATA) No Connection
H1/3 Tan/Black (DATA) HS CAN High
H1/4 Tan (DATA) HS CAN Low
H1/5 Orange/Green (DATA) HS CAN High
H1/6 Orange/Brown (DATA) HS CAN Low
H1/7 Brown Relay N.O. Pk Light Output
H1/8 Yellow Relay COM Pk Light Output
H1/9 Orange or Orange/Yellow Relay N.C. Pk Light Output
H1/10 Orange/Red Relay N.C. Key Wrap
H1/11 Yellow/Red Relay COM Key Wrap
H1/12 Brown/Red Relay N.O. Key Wrap
H1/13 Red (+) 12 Volt
H1/14 Black (-) Ground
Output 12-pin red connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Ref.
H2/1 Black/White (-) Hazard Light Output
H2/2 Green/Black
(-) PTS
[4]
H2/3 Green/White (-) No Connection
H2/4 Red/Black (-) Trunk Output
H2/5 Violet/White (AC) No Connection
H2/6 Gray (+) Brake Output
H2/7 Gray/Black (+) No Connection
H2/8 Violet/Green (MUX) No Connection
H2/9 Violet/Brown (MUX) PTS
H2/10 Yellow/Black No Connection
H2/11 Orange/Black No Connection
H2/12 Blue/Red (-) No Connection
To Next Page
