Directed DBALL2 User Manual

Platform: DBALL2
Firmware: CHRYSLER Remote Start Ready (RSR) Installation
© 2017 Directed. All rights reserved.
Rev.: 20170214
Type 7 - Vehicle Wiring Reference Chart
Page 23
Function Color Pin Polarity Location Color Pins
Chrysler 300/300c 2005-2007
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White 7 Data Sentry Key Module near ignition switch. Black 8
12V Red or Red/Striped 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 2 MUX Ignition switch. Black 5 or 6
Ignition Pink/Green 3 (+) Ignition switch. Black 5 or 6
Starter Pink/Dk. Green 4 (+) Ignition switch. Black 5 or 6
Parking Lights White/Violet N/A (+) Passenger kick panel harness. N/A N/A
Parking Lights Relay Power Red/White N/A (+) Passenger kick panel harness. N/A N/A
Chrsyler PT Cruiser 2006-2010
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White 7 Data Sentry Key Module near ignition switch. Black 8
12V Red or Red/Striped 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 2 MUX Ignition switch. Black 5 or 6
Ignition Pink/White 3 (+) Ignition switch. Black 5 or 6
Starter Pink/Lt.Blue 4 (+) Ignition switch. Black 5 or 6
Parking Lights White/Violet N/A (+) Driver kick, harness to rear. N/A N/A
Parking Lights Relay Power Lt.Blue/Red 4 (+) Junction connector above OBDII. Black N/A
Dodge Charger 2006-2007
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White 7 Data Sentry Key Module near ignition switch. Black 8
12V Red or Red/Striped 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 2 MUX Ignition switch. Black 5 or 6
Ignition Pink/Green 3 (+) Ignition switch. Black 5 or 6
Starter Pink/Orange 4 (+) Ignition switch. Black 5 or 6
Parking Lights White/Violet N/A (+) Passenger kick panel harness. N/A N/A
Parking Lights Relay Power Red/White N/A (+) Passenger kick panel harness. N/A N/A
Dodge Magnum 2005-2007
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White 7 Data Sentry Key Module near ignition switch. Black 8
12V Red or Red/Striped 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 2 MUX Ignition switch. Black 5 or 6
Ignition Pink/Green 3 (+) Ignition switch. Black 5 or 6
Starter Pink/Orange 4 (+) Ignition switch. Black 5 or 6
Parking Lights White/Violet N/A (-) Passenger kick panel harness. N/A N/A
Parking Lights Relay Power Red/White N/A (+) Passenger kick panel harness. N/A N/A
Dodge RAM 2006
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White 7 Data Sentry Key Module near ignition switch. Black 8
12V Red or Red/Striped 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 2 MUX Ignition switch. Black 5 or 6
Ignition Pink/Green 3 (+) Ignition switch. Black 5 or 6
Starter Pink/Orange 4 (+) Ignition switch. Black 5 or 6
Hazards White/Orange 5 (-) Hazard switch or Instrument cluster. Gray 16
Parking Lights Relay Power Tan/Red 4 (+) Electric brake conn. above junction connector. Blue 4
Jeep Commander 2006-2007
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White 7 Data Sentry Key Module near ignition switch. Black 8
12V Red or Red/Striped 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 2 MUX Ignition switch. Black 5 or 6
Ignition Pink/Green 3 (+) Ignition switch. Black 5 or 6
Starter Pink/Orange 4 (+) Ignition switch. Black 5 or 6
Hazards White/Dk. Blue to White/Tan 16 (-) SCM (Steering Column module) in steering column. N/A 16
Parking Lights Relay Power Red 40 (+) Top connector above fuses. Black 40
Jeep Grand Cherokee 2005-2007
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White 7 Data Sentry Key Module near ignition switch. Black 8
12V Red or Red/Striped 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 2 MUX Ignition switch. Black 5 or 6
Ignition Pink/Green 3 (+) Ignition switch. Black 5 or 6
Starter Pink/Orange 4 (+) Ignition switch. Black 5 or 6
Hazards White/Dk. Blue 16 (-) SCM (Steering Column module) in steering column. N/A 16
Parking Lights Relay Power Red 40 (+) Top connector above fuses. Black 40
