Directed DBALL2 User Manual

Platform: DBALL2
Firmware: CHRYSLER Remote Start Ready (RSR) Installation
© 2017 Directed. All rights reserved.
Rev.: 20170214
2
7 8
9
3
4
5
6 10
1
Headlight switch
(black 10-pin conn.)
(-) RAP Off Output: Yellow/Black: 10
Parking Light MUX Output: Violet/Green: 8
Parking Light MUX Output: Violet/Brown: 9
Ignition
Barrel
12-pin Connector
(Vehicle side)
12-pin Connector
(harness side)
12-pin Connector
(harness side)
P
USH
TO
RELE
ASE
Driver
Kick
Panel
(-) Driver Door
Trigger: Violet
(MUX)
Parking Lights:
Pin 1
[1] (+) Parking Lights: White/Violet, pin 3
[1] Parking Light Output: Green/Black: 2
Connect parking
lights in drivers
kick panel for
Dodge Journey only.
Refer to the Vehicle Wiring Reference Charts for wire color and location.
This is the only connection required for the
parking light output for the Dodge Journey.
The DBALL MUX connection is not required.
30
86
85
87
87a
Dodge Journey
(+) Parking Lights
White/Violet
Fuse 15A
+12V
ONLY connect for
Dodge Journey.
CHTHD1 (R1-R7)
/ THCHD1 (R1)
(optional)
Installation Type 1 - with CHTHD1 (R1-R7) /THCHD1 (R1) T-Harness
Page 3
10
DBALL2
RF
Prog. Button
LED
4
14 12 2
TX
(-) Ground
RX
(+) 12V
6: White/Black: (-) Hood Input
Hood Pin
Remote Start Safety
Override Switch
You can connect to either a XL202
RFTD OR a SmartStart module.
Refer to the SmartStart/XL202
Installation Notes for more information.
All connectors are displayed from the wire side (unless specified otherwise).
[1] Connected to the Dodge Journey only. DO NOT connect Parking Light Input to (+)12V at the ignition switch.
