Directed DBALL2 User Manual

Platform: DBALL2
Firmware: CHRYSLER Remote Start Ready (RSR) Installation
© 2017 Directed. All rights reserved.
Rev.: 20170214
Page 8
Type 2 - Vehicle Wiring Reference Chart
Function Color Pin Polarity Location Color Pins
Chrysler Tow n & Country 2011-2016
HS CAN High White/Lt.Blue 5 Data Wireless Ignition Node on ignition switch. Black 12
HS CAN Low White/Brown 6 Data Wireless Ignition Node on ignition switch. Black 12
Ignition Pink/White 3 (+) Wireless Ignition Node on ignition switch. Black 12
12V Lt.Blue/Red 1 (+) Wireless Ignition Node on ignition switch. Black 12
Ground Black or Black/Striped 4 (-) Wireless Ignition Node on ignition switch. Black 12
Parking Lights White/Green 3 MUX Headlight switch. Black 6
Driver Door Trigger Violet N/A N/A Drivers kick door harness. N/A N/A
Dodge C/V 2012-2016
HS CAN High White/Lt.Blue 5 Data Wireless Ignition Node on ignition switch. Black 12
HS CAN Low White/Brown 6 Data Wireless Ignition Node on ignition switch. Black 12
Ignition Pink/White 3 (+) Wireless Ignition Node on ignition switch. Black 12
12V Lt.Blue/Red 1 (+) Wireless Ignition Node on ignition switch. Black 12
Ground Black or Black/Striped 4 (-) Wireless Ignition Node on ignition switch. Black 12
Parking Lights White/Green 3 MUX Headlight switch. Black 6
Driver Door Trigger Violet N/A N/A Drivers kick door harness. N/A N/A
Dodge Durango 2011-2013
HS CAN High White/Lt.Blue 5 Data Wireless Ignition Node on ignition switch. Black 12
HS CAN Low White/Brown 6 Data Wireless Ignition Node on ignition switch. Black 12
Ignition Pink/White 3 (+) Wireless Ignition Node on ignition switch. Black 12
12V Red 1 (+) Wireless Ignition Node on ignition switch. Black 12
Ground Black or Black/Striped 4 (-) Wireless Ignition Node on ignition switch. Black 12
Parking Lights White/Green 3 MUX Headlight switch. Black 6
Driver Door Trigger Violet N/A N/A Divers kick door harness. N/A N/A
Dodge Gra nd Ca ravan 2011-2017
HS CAN High White/Black 5 Data W ireless Ignition Node on ignition switch. Black 12
HS CAN Low White/Lt.Blue 6 Data W ireless Ignition Node on ignition switch. Black 12
Ignition Pink/White 3 (+) Wireless Ignition Node on ignition switch. Black 12
12V Lt.Blue/Red 1 (+) Wireless Ignition Node on ignition switch. Black 12
Ground Black or Black/Striped 4 (-) Wireless Ignition Node on ignition switch. Black 12
Parking Lights White/Green 3 MUX Headlight switch. Black 6
Driver Door Trigger Violet N/A N/A Drivers kick door harness. N/A N/A
Volksw agen Routan 2011-2013
HS CAN High White/Lt.Blue 5 Data Wireless Ignition Node on ignition switch. Black 12
HS CAN Low White/Brown 6 Data Wireless Ignition Node on ignition switch. Black 12
Ignition Pink/White 3 (+) Wireless Ignition Node on ignition switch. Black 12
12V Lt.Blue/Red 1 (+) Wireless Ignition Node on ignition switch. Black 12
Ground Black or Black/Striped 4 (-) Wireless Ignition Node on ignition switch. Black 12
Parking Lights White/Green 3 MUX Headlight switch. Black 6
Driver Door Trigger Violet N/A N/A Drivers kick door harness. N/A N/A
Wire Information Connector Informa tion
