Directed DIRECTWIRE DIRECTECHS 933.TL14 User Manual

37
DS4+ FORD6
© 2017-12-13 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford E-Series 2009-2014
RX Violet/Gray 3 Data (PATS) connector. Green 4 A
TX Yellow/Orange 4 Data (PATS) connector. Green 4 A
12V Blue/Red 2 (+) Ignition switch. Gray or
Black
13 B
Starter Blue/White 5 (+) Ignition switch. Gray or
Black
13 B
Ignition White/Orange 1 (+) Ignition switch. Gray or
Black
13 B
Accessory 1 Brown/Yellow 8 (+) Ignition switch. Gray or
Black
13 B
Accessory 2 Violet/Green 3 (+) Ignition switch. Gray or
Black
13 B
Parking Lights Violet/White 6 (+) SJB (Smart Junction Box) under drivers dash. Gray 13 F
HS CAN High White/Blue 6 Data OBDII. Black 16 C
HS CAN Low White 14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C
Driver Door Trigger Green/Violet 14 (-) SJB under drivers dash. Gray 26 G
Lock Gray/Yellow 17 (-) SJB under drivers dash. Gray 26 G
Unlock Violet/Gray 4 (-) SJB under drivers dash. Gray 26 G
Tach White/Pink N/A (AC) "Customer Access Harness is around the middle of the
main harness that runs along the top of the firewall,
under the hood."
N/A N/A N/A
