DS4+ FORD6

Wire Information Connector Information

Function Color Pin Polarity Location Color Pins Ref.

Lincoln MKZ 2010-2012

RX Yellow/Orange 4 Data (PATS) connector. Black 4 A

TX Violet/Gray 3 Data (PATS) connector. Black 4 A

12V Blue/Red 4 (+) Ignition switch. Black 7 B

Starter Blue/White 7 (+) Ignition switch. Black 7 B

Ignition White/Orange 1 (+) Ignition switch. Black 7 B

Accessory Violet/Green 6 (+) Ignition switch. Black 7 B

Keysense Blue/Gray 5 (+) Ignition switch. Black 7 B

Parking Lights Violet/White 6 (+) Fuse/SJB (Smart Junction Box) under

drivers dash.

Gray 13 H

HS CAN High White/Blue 6 Data OBDII. Black 16 C

HS CAN Low White 14 Data OBDII. Black 16 C

MS CAN High Gray/Orange 3 Data OBDII. Black 16 C

MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C

Driver Door Trigger Green/Violet 14 Cut Fuse/SJB under drivers dash. Gray 26 G

Lock Gray/Yellow or Blue/Green 17 (-) Fuse/SJB under drivers dash. Gray 26 G

Unlock Violet/Gray or Yellow/

Violet

4 (-) Fuse/SJB under drivers dash. Gray 26 G

Trunk/Hatch Release Gray/Yellow or Brown/

Yellow

20 (-) Fuse/SJB under drivers dash. Gray 26 G

Tach Green/Blue, Gray/Yellow,

Violet/Gray, Yellow/

Orange, Brown, Green/

White

1 (AC) Any fuel injector. N/A 2 N/A

Mercury Milan 2010-2011
