Directed DS3+

8
933.HONDA9 2.10.198.12 2018 Honda Civic (Smart Key)
©2023 Directed. All rights
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
10
27
32
(+) 12V Input: Red: 6 & 12
(-) Ground: Black: 10
(-) Takeover Output: Dk.Blue/Black: 9
87a87
85 86
30
Cut
1A Diode (1N4002+)
87a87
85 86
30
Cut
1A Diode (1N4002+)
8616
Mini
Relay
87a87
Orange
8616 wire and color reference
Brown
Yellow
Black Red
85 86
30
8616
Mini
Relay
8616
Mini
Relay
5A Fuse
27
BCM
(gray connector)
BCM
(black connector)
1
116
17
14
28
15
BCM
connectors
(behind or above dash fuse box)
(+) 12V: Red, pin 27
Ignition Interrupt 3:
Yellow, pin 10
Ignition Interrupt 4:
Red or Lt. Green, pin 27
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
22 812
4 2442
Slide to open
A module can also be used for
this installation.
IMPORTANT:
Position the
fuses correctly!
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT (15A) (+)
5
5
30
20
20
15
15
Vehicle takeover additional connections
•Hardwire installations - required for takeover. For T-Harness installations, DO NOT make connections on this diagram, they have relays built-in.
•Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
