Directed DS3+

14
933.HONDA9 2.10.198.12 2018 Honda Civic (Smart Key)
©2023 Directed. All rights
Module programming
Refer to “LED diagnostics and troubleshooting” for more information and for troubleshooting purposes.
ForSecurity-OnlyandConvenience-Onlyprogramming, see next sections.
1
IMPORTANT!The vehicle battery must be in good condition and fully charged for successful
programming. A battery charger may be connected during programming if necessary.
2
Ensure vehicle is in a safe location, and cannot move forward during programming. For
vehicles equipped with a manual transmission, make sure the gearshift is in the neutral
position.
3
Connect the 12-pin main power harness to the module.
DS3+: Wait until the LED turns ON solid red then proceed to the next step.
DS4+: The LED turns ON solid blue for 1 second to confirm Bluetooth communication. Wait
until the LED turns ON solid red, then proceed to the next step.
4
Connect the remaining harnesses to the module.
5
With the brake depressed, press the Push-to-Start (PTS) button once (1) to start the vehicle.
The LED flashes orange quickly for approximately 5 seconds, then flash green (may flash
green for 30-60 seconds).
6
Wait 30 to 60 seconds.
If the LED turns ON solid green for 3 seconds then shuts OFF, configuration is
completed, proceed to step 8.
-
If the LED flashes red 4 times, see Alternate module programming in the following
section.
-
If the LED starts flashing orange slowly,additional Key2GO programming steps below
are required.
-
7
Key2GO Programming
Press the PTS button once (1) more to turn the ignition OFF.1.
Remove the module from the vehicle, and reconnect it to your computer. The web site
will automatically recognize that you are moving onto the second phase of the
programming sequence.
2.
Click onSubmit Key2GO Request.3.
Once the configuration is completed, reconnect the module.4.
The LED turns ON solid green for 3 seconds then shuts OFF.5.
Proceed to the next step.6.
