DS4+ FORD6

Wire Information Connector Information

Function Color Pin Polarity Location Color Pins Ref.

Ford F350 2011-2016

RX Yellow/Orange 4 Data (PATS) connector. Black 4 A

TX Violet/Gray 3 Data (PATS) connector. Black 4 A

12V Blue/Red or Green/Red 4 (+) Ignition switch. Black 7 B

Starter Blue/White 7 (+) Ignition switch. Black 7 B

Ignition White/Orange 1 (+) Ignition switch. Black 7 B

Accessory Violet/Green 6 (+) Ignition switch. Black 7 B

Keysense Blue/Gray 5 (+) Ignition switch. Black 7 B

Parking Lights Yellow/Blue 6 (+) SJB (Smart Junction Box) passenger kick

panel.

Gray 10 J

HS CAN High White/Blue 6 Data OBDII. Black 16 C

HS CAN Low White 14 Data OBDII. Black 16 C

MS CAN High Gray/Orange 3 Data OBDII. Black 16 C

MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C

Driver Door Trigger Green/Violet 9 Cut SJB passenger kick panel. Black 26 I

Lock Blue/Green 6 (-) SJB passenger kick panel. Black 26 I

Unlock Yellow/Violet 8 (-) SJB passenger kick panel. Black 26 I

Tach Blue N/A (AC) Customer Access Harness above driver

kick, taped to wiring harness. On models

without the Customer Access Harness, go

to any fuel injector and use the wire that

is not blue (gasoline), or use the camshaft

position sensor, which is white/green

at the Powertrain Control Module on

passenger side of engine, middle, black

98 pin plug, pin 32 (diesel).

Gray 2 N/A

Ford F450 2011-2016
