Directed DS3+

12
933.HONDA9 2.10.198.12 2018 Honda Civic (Smart Key)
©2023 Directed. All rights
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H2/12 Pink (+) Ignition Sense Input No Connection
H2/13 Violet (+) Door Trigger Input No Connection
H2/14 Brown (+) Brake Input No Connection
H2/15 White/Blue (-) Activation Input No Connection
H2/16 Red/Blue (-) Headlight Detection Input No Connection
H2/17 Black/White (-) E-Brake Input No Connection
H2/18 Orange/Black (+) Instant Trigger Input No Connection
H2/19 Blue (-) Trunk Trigger Input No Connection
H2/20 Green (-) Door Trigger Input No Connection
H2/21 Gray
(-) Hood Switch Input [1]
H2/22 Violet/White (AC) Tach Input No Connection
Main harness, 12-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H3/1 Blue/White
Relay N.C. - Ignition Interrupt 2 (vehicle side) [3]
Required for installations WITH vehicle takeover ONLY.
Steering Lock Module under steering column, gray 12 pin plug, pin 12
The steering lock connection is ONLY required if the connector is present
in the vehicle.
Cut Blue
Remote Start
Only
H3/2 Blue/Red Relay N.O. - No Connection No Connection
H3/3 Blue
Relay COM - Ignition Interrupt 2 (conn. side) [3]
Required for installations WITH vehicle takeover ONLY.
Steering Lock Module under steering column, gray 12 pin plug, pin 12
The steering lock connection is ONLY required if the connector is present
in the vehicle.
Cut Blue
Remote Start
Only
H3/4 White/Brown Relay N.C. - No Connection No Connection
H3/5 White Relay COM - (+) Accessory Output BCM behind dash fuse box, black 32 pin plug, pin 32 + Gray
Remote Start
Only
H3/6 Red (+) 12 Volt Input BCM behind dash fuse box, gray 28 pin plug, pin 27 + Red (10A)
Mandatory
H3/7 Lt. Green/Red Relay N.O. - (+) 12 Volt Input BCM behind dash fuse box, gray 28 pin plug, pin 27 + Red (10A)
Remote Start
Only
H3/8 Lt. Green Relay COM - Ignition Interrupt 1 (vehicle side) BCM behind dash fuse box, gray 36 pin plug, pin 2 Cut Pink
Remote Start
Only
H3/9 Lt. Green/White Relay N.C. - Ignition Interrupt 1 (conn. side) BCM behind dash fuse box, gray 36 pin plug, pin 2 Cut Pink
Remote Start
Only
H3/10 Black (-) Ground (chassis ground)
Mandatory
H3/11 White Relay COM - (+) Accessory Output BCM behind dash fuse box, black 32 pin plug, pin 32 + Gray
Remote Start
Only
H3/12 Red (+) 12 Volt Input BCM behind dash fuse box, gray 28 pin plug, pin 27 + Red (10A)
Mandatory
Relay harness, 10-pin white connector (H4)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
