Directed DS3+

9
933.HONDA9 2.10.198.12 2018 Honda Civic (Smart Key)
©2023 Directed. All rights
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
BCM
(behind or above
dash fuse box)
9
32
2
9
(+) 12V:
Red or White,
pin 27
Wiring diagram without Vehicle Takeover
Immo.
Data:
Yellow
or Red ,
pin 35
(-) Parking
Lights:
White or Gray,
pin 11
11
35
27
20
21
22
23
B-CAN High:
Pink, pin 20
B-CAN Low:
Tan or Blue, pin 21
(-) PTS: Blue or Black, pin 9
(+) Accessory:
Gray, pin 32
Siren
Hood Pin
(-) Hood Input: Gray: 21
(+) Siren Output: Brown/Red: 11
Immobilizer Data: Yellow/Black: 8
(-) Parking Lights Output: Lt. Blue/Black: 10
(-) Push-To-Start Output: Lt. Green/Black: 1
(+) Starter Output: Violet/Black: 8
(+) 12V Input: Lt. Green/Red: 7
(+) Accessory Output: White: 5 & 11
(+) 12V Input: Red: 6 & 12
(-) Ground: Black: 10
OBDII
Diagnostic
Connector
16
8
9
1
DIAG-CAN High: Green or White, pin 6
DIAG-CAN Low:
Red or Tan, pin 14
Ignition Interrupt 1 (vehicle side): Lt. Green: 8
Ignition Interrupt 1 (connector side): Lt. Green/White: 9
Ignition Interrupt 1:
White or Pink, pin 2
(+) Starter: Lt. Blue
or Yellow, pin 6
Cut
Refer to the Optional starter disable
connection section for relay and
connection details.
(-) GWA Output: Red/White: 4
HS CAN Low 2: Tan: 1
HS CAN High 2: Tan/Black: 2
HS CAN High 1: Orange/Green: 4
HS CAN Low 1: Orange/Brown: 3
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
22 812
4 2442
Slide to open
A module can also be used for
this installation.
IMPORTANT:
Position the
fuses correctly!
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT (15A) (+)
5
5
30
20
20
15
15
F-CAN Low: Pin 23
OR
F-CAN High: Pin 22
BCM
connectors
(behind or above dash fuse box)
