Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford Escape 2008-2012
RX Violet/Gray 4 or
3
Data (PATS) connector. Black 4 A
TX Yellow/Orange 3 or
4
Data (PATS) connector. Black 4 A
12V Blue/Red 4 (+) Ignition switch. Black 7 B
Starter Blue/White 7 (+) Ignition switch. Black 7 B
Ignition White/Orange 1 (+) Ignition switch. Black 7 B
Accessory Violet/Green 6 (+) Ignition switch. Black 7 B
HS CAN High White/Blue 6 Data OBDII. Black 16 C
HS CAN Low White 14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C
Driver Door Trigger Green/Violet 14 Cut SJB (Smart Junction Box) passenger side of the center console. Gray 26 F
Trunk/Hatch Release Brown 7 (+) SJB passenger side of the center console. Gray 26 F
Lock Blue/Green 17 (-) SJB passenger side of the center console. Gray 26 F
Unlock Yellow/Violet 4 (-) SJB passenger side of the center console. Gray 26 F
Parking Lights Violet/White 20 (+) SJB passenger side of the center console. Black 32 G
Factory Alarm Disarm Violet/Brown N/A (-) Drivers kick panel, door harness. N/A N/A H
Tach Green/Blue, Gray/
Yellow, Violet/Gray,
Yellow/Orange,
Brown, Green/White
1 (AC) Any fuel injector. N/A 2 N/A
Ford Escape Hybrid 2008-2012
RX Violet/Gray 4 or
3
Data (PATS) connector. Black 4 A
TX Yellow/Orange 3 or
4
Data (PATS) connector. Black 4 A
12V Blue/Red 4 (+) Ignition switch. Black 7 B
Starter Blue/White 7 (+) Ignition switch. Black 7 B
Ignition White/Orange 1 (+) Ignition switch. Black 7 B
Accessory Violet/Green 6 (+) Ignition switch. Black 7 B
HS CAN High White/Blue 6 Data OBDII. Black 16 C
HS CAN Low White 14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C
Driver Door Trigger Green/Violet 14 Cut SJB (Smart Junction Box) passenger side of the center console. Gray 26 F
Trunk/Hatch Release Brown 7 (+) SJB passenger side of the center console. Gray 26 F
Lock Blue/Green 17 (-) SJB passenger side of the center console. Gray 26 F
Unlock Yellow/Violet 4 (-) SJB passenger side of the center console. Gray 26 F
Parking Lights Violet/White 20 (+) SJB passenger side of the center console. Black 32 G
Factory Alarm Disarm Violet/Brown N/A (-) Drivers kick panel, door harness. N/A N/A H
Tach Green/Blue, Gray/
Yellow, Violet/Gray,
Yellow/Orange,
Brown, Green/White
1 (AC) Any fuel injector. N/A 2 N/A
