Page 70
Installation Instructions
Chapter 4
DISHPRO WIRING DIAGRAMS
DISH 500, ONE DISHPRO TWIN LNBF, TWO DISHPRO
R
ECEIVERS
This diagram leaves out grounding to be clear. Make sure
you ground the system per the National Electrical Code
(NEC) and all local electrical codes. Please see Ground
the System on page page 90 for more information.
When you set up your system following this diagram and run Check
Switch the Installation Summary screen should look similar to
the one shown below.
