VP30 Operator’s Manual Overview - 5
Operator Orientation
Operator Orientation
1. Front of unit
2. Right side of unit
3. Rear of unit
4. Left side of unit
Operating Area
The operating area (A) is at the rear of the
machine, behind the control console.
Any other area less than 6 ft (2 m) from the
machine is a hazardous area (B). Stay away
while operational.
Moving parts could cut off hand or foot. Stay away.
275-184, 273-546
