Drill - 64 VP30 Operator’s Manual
Operate
Add Rod Section
1. Shut down machine.
2. Have helper connect new rod section to drilling attachment.
3. Start machine and set engine to low throttle.
4. Slowly move machine forward until new rod section and drill string are about 1’ (30 cm) apart.
5. Have helper lightly hold new rod section and drill string so that they are aligned.
6. Rotate drilling attachment to align slip latches of new rod section and drill string.
7. Move machine forward slowly. As soon as new rod section and drill string are connected, have helper
move hands clear.
8. Slightly move forward until the slip latch connection is correctly latched.
Pinch point. Crushing will cause serious injury.
To help avoid injury:
• Keep hands at least 6” (15 cm) from ends of rod section and drill string.
• Support rods from underneath with open palms. Do not grip rods.
