DITEC CS12M Technical Manual

6
IP2160EN
1. Technical specifications
Ditec NES400EH Ditec NES400EHP Ditec NES400EHJ
Power supply 230 V~ 50/60Hz 230 V~ 50/60Hz 120 V~ 50/60Hz
Absorption 1,2 A 1,2 A 2,4 A
Fuse F2A F2A F4A
Thrust 400 N 400 N 400 N
Wing speed 0,1÷0,25 m/s 0,1÷0,25 m/s 0,1÷0,25 m/s
Max stroke 12 m 12 m 12 m
Max wing weight 400 kg 400 kg 400 kg
Service class 4 - INTENSE 4 - INTENSE 4 - INTENSE
Intermittence S2 = 30 min - S3 = 50% S2 = 30 min - S3 = 50% S2 = 30 min - S3 = 50%
Operating
temperature
-20° C +55° C -20° C +55° C -20° C +55° C
-35° C +55° C
with active NIO
-35° C +55° C
with active NIO
-35° C +55° C
with active NIO
Degree of protection IP24 IP24 IP24
Control panel CS12E CS12M CS12E
Ditec
NES600EH
Ditec
NES600EHP
Ditec
NES600EHSF
Ditec
NES600EHJ
Ditec
NES600EHSFJ
Power supply 230 V~ 50/60Hz 230 V~ 50/60Hz 230 V~ 50/60Hz 120 V~ 50/60Hz 120 V~ 50/60Hz
Absorption 1,5 A 1,5 A 1,5 A 3 A 3 A
Fuse F2A F2A F2A F4A F4A
Thrust 600 N 600 N
300 N nominal
500 N start-up
600 N
300 N nominal
500 N start-up
Wing speed 0,1÷0,24 m/s 0,1÷0,24 m/s 0,1÷0,4 m/s 0,1÷0,24 m/s 0,1÷0,4 m/s
Max stroke 20 m 20 m 20 m 20 m 20 m
Max wing weight 600 kg 600 kg 600 kg 600 kg 600 kg
Service class 4 - INTENSE 4 - INTENSE 4 - INTENSE 4 - INTENSE 4 - INTENSE
Intermittence
S2 = 30 min
S3 = 50%
S2 = 30 min
S3 = 50%
S2 = 30 min
S3 = 50%
S2 = 30 min
S3 = 50%
S2 = 30 min
S3 = 50%
Operating
temperature
-20° C +55° C -20° C +55° C -20° C +55° C -20° C +55° C -20° C +55° C
-35° C +55° C
with active NIO
-35° C +55° C
with active NIO
-35° C +55° C
with active NIO
-35° C +55° C
with active NIO
-35° C +55° C
with active NIO
Degree of protection IP24 IP24 IP24 IP24 IP24
Control panel CS12E CS12M CS12E CS12E CS12E
