7
IP2160EN
1.1 Operating instructions
Applications: INTENSE (for apartment block, industrial and commercial entrances and car parks
with vehicle access or access for intense pedestrian use).
- Performance characteristics are to be understood as referring to the recommended weight (ap-
prox. 2/3 of maximum permissible weight). When used with the maximum permissible weight
a reduction in the above mentioned performance can be expected.
- Service class, running times, and the number of consecutive cycles are to be taken as merely
indicative, having been statistically determined under average operating conditions, and are
therefore not necessarily applicable to specific conditions of use.
- Each automatic entrance has variable elements such as: friction, balancing and environmental
factors, all of which may substantially alter the performance characteristics of the automatic
entrance or curtail its working life or parts thereof (including the automatic devices themselves).
The installer should adopt suitable safety conditions for each particular installation.
Ditec NES1000EHP Ditec NES1000EHPJ
Power supply 230 V~ 50/60Hz 120 V~ 50/60Hz
Absorption 2 A 4 A
Fuse F2,5 A F6,3A
Thrust 1000 N 1000 N
Wing speed 0,1÷0,19 m/s 0,1÷0,19 m/s
Max stroke 20 m 20 m
Max wing weight 1000 kg 1000 kg
Service class 4 - INTENSE 4 - INTENSE
Intermittence
S2 = 30 min
S3 = 50%
S2 = 30 min
S3 = 50%
Operating temperature
-20° C +55° C -20° C +55° C
-35° C +55° C
with active NIO
-35° C +55° C
with active NIO
Degree of protection IP24 IP24
Control panel CS12M CS12M
1.2 Machinery Directive
Pursuant to Machinery Directive (2006/42/EC) the installer who motorises a door or gate has the
same obligations as the manufacturer of machinery and as such must:
- prepare the technical data sheet which must contain the documents indicated in Annex V of the
Machinery Directive; (The technical data sheet must be kept and placed at the disposal of competent
national authorities for at least ten years from the date of manufacture of the motorised door);
- draw up the EC Declaration of Conformity in accordance with Annex II-A of the Machinery Direc-
tive and deliver it to the customer;
- affix the EC marking on the motorised door or gate, in accordance with point 1.7.3 of Annex I of
the Machinery Directive;
- ensure compliance of the motorised door or gate with safety regulations, by installing the neces-
sary safety devices;
- carry out the safety test , modifying parameters and (if used) from the menu;
- refer to the installation manual of the CS12E - CS12M control panel for the operating force
adjustments, in compliance with EN12453 and EN12445.
