Section 5 Technical Summary of Transceiver FSG 7016
5.1 Leading Particulars
Model:
Handheld UHF/AM Aviation Transceiver FSG 7016
Article-No. F10165
Frequency Range: 225.000 MHz to 399.975 MHz
Channel Spacing: 25 kHz
Number of Channels: 16 pre-set channels out of 7,000 channels
Channel Selection: by 16-position rotary switch
Operating Mode: Simplex (either receiving or transmitting)
Modulation: AM A3E, 350 … 2,500 Hz
Antenna Connection. TNC, 50 ohm
Antenna: Flexible Helix Antenna
Power Supply: Detachable, rechargeable 12 Vdc nickel-metal hydride
(Ni-MH) battery pack, 1,500 mAh, with built-in
temperature sensor.
External 10 Vdc to 15 Vdc via 10-pole accessory
connector, input current 1.2 A maximum.
Switched 12 Vdc output for attached accessories,
drain 150 mA maximum.
Current drain: Standby (STBY): 55 mA
Receive RX: 260 mA at nominal AF power,
Transmit TX: 1.2 A into 50 / 1 Watt
Operating Time: 6 to 23 hours, depends on operating mode
Additional features: Rugged, milled Aluminium chassis (water- and dustproof)
VOX: Integrated voice operated transmitting via helmet
microphone, can be switched off.
External microphone switches off built-in speaker and
microphone.
5.2 Transmitter Characteristics:
Power Output: Programmable to 0 W / 0.1 W / 0.4 W / 1.0 W into 50
Frequency Accuracy: ± 3 ppm = 1.2 kHz at 25°C
± 6.5 ppm = 2.6 kHz from -20°C to +60°C
Spurious/Harmonic
Radiation:
-60 dBc @ 50 Ohm
Adjacent Channel
Suppression:
at ± 25 kHz -65 dB, m = 60% / 1,250 Hz
Modulation AF Response: -6 dB @ 350 Hz … 2,500 Hz
AF Distortion Factor: 10% @ 1 kHz / m = 70%
Modulation Capability: 70% (processed by built-in modulation compressor)
Microphone Level: 1 mV to 10 mV
TX Sidetone: derived from the Microphone amplifier
