FSG 7016
1 General Description
November 2009 7
Section 1 General Description
1.1 Introduction
This Operator's Manual contains information relative to the physical, mechanical
and electrical characteristics of the Dittel Messtechnik GmbH FSG 7016 handheld
water- and dustproof UHF/AM Communications Transceiver with VOX controlled
transmit.
This excellent transceiver system FSG 7016, article no F10165, manufactured by
Dittel Messtechnik GmbH, 86899 Landsberg am Lech, Germany, is a
microprocessor controlled, high performance, 16-channels pre-set, handheld
UHF/AM air band transceiver, complete with rechargeable, snap-on battery pack,
helical antenna and removable, adjustable carrying strap on the radio's rear side.
Every unit leaves our factory only after extensive tests.
1.2 Equipment Description
This light weight, small size, splash and dust proof transceiver offers universal
operation on up to 16 fixed, software pre-programmed channels at 25 kHz spacing
out of 7,000 channels within the full UHF/AM 225.000 MHz to 399.975 MHz
frequency range. The rechargeable 1,500 mAh high capacity Ni-MH battery,
together with three programmable RF output levels plus 'receive only' mode on any
channel, allow very flexible operations.
The operating mode is Simplex, i.e. transmitting or receiving only in turns.
Excellent collocation characteristics - especially the very high receiver sensitivity -
allow universal, flexible and reliable line of sight voice radio communications also in
difficult environment. Due to a built-in voice controlled communication function
(VOX) -transmitting without pressing any PTT key - both hands get therefore free
for other jobs. Very long battery operating times are available for independent hand
portable, body worn, and mobile use, and even for long distance fixed base
operations, where a wide band roof top external antenna (antistatic grounded) is
used.
Battery replacement or discharge does not result in loss of memory information.
A comprehensive manually or automatically activated acoustic and LED battery
status control, besides the high level transmit side tone, gives the operator easy to
understand battery status information, most useful at difficult missions. This is
especially helpful in extreme operating conditions, e.g. as helicopter winch men or
for parachute missions.
The audio volume is adjustable in seven steps to control receive, transmit side
tone, and battery status/warning beep tones.
External microphone sensitivity can be easily set in seven steps.
Both - the built-in microphone and internal loudspeaker - are switched OFF, when
an external microphone is connected to the multifunction 10-pole accessory socket.
Together with a wide range of accessories, this high performance light weight
handy UHF/AM radio is especially suitable for reliable use also under extremely
difficult environmental operating conditions.
1.2.1 Sophisticated Programming
Easy interfacing through the 10-pole accessory socket, using a special DITTEL
adapter cable to any standard Personal Computer running WINDOWS 98, NT,
2000 or XP, allows simple and quick control, selection, and reprogramming on any
of the 16 memory channels. Any combination of frequency and / or RF output
power selection / programming is possible.
