FSG 7016
Operator’s Manual
4 D10011 November 2009
Abbreviations and Acronyms
A/C Aircraft
A/N Article Number (Dittel
Messtechnik GmbH)
AGC Automatic Gain Control
Ah Ampere hour
AM Amplitude Modulation
ANT Antenna
Ass'y Assembly
AWG American Wire Gauge
ccw
Counterclockwise (turn left ↺)
CH Channel
cont'd Continued
CTS Ready-to-Transmit
cw
Clockwise (turn right ↻)
dB Decibel
dia. Diameter
EMF Electromotive Force (voltage of
an open circuit)
F/CH Frequency/Channel
FL Flight Level
g Acceleration due to gravity
GHz Gigahertz (1,000,000,000 Hz)
GND Ground
HI High Power
Hz Hertz
IF Intermediate Frequency
kHz Kilohertz (1,000 Hz)
LCD Liquid Crystal Display
LED Light Emitting Diode
LO Low Power
LOS Line-Of-Sight
m Modulation
mA Milliamperes (1/1000 A)
MD Mode
MHz Megahertz (1,000,000 Hz)
MIC Microphone
ms Millisecond (1/1000 sec)
mW Milliwatt (10
-3
W)
NM Nautical miles (1.852 km)
nW Nanowatt (10
-9
W)
PEP Peak Envelope Power
PLL Phase-Locked Loop
ppm Parts per million
PTT Push-To-Talk
pW Picowatt (10
-12
W)
PWR Power
RF Radio Frequency
rms Effective value
(root mean square)
RTS Invitation to send
RX Receive
RxD Receive data
S+N/N Signal-to-Noise Ratio
SINAD
Ratio:
Signal noise distortion
noise distortion
++
+
SPKR Loudspeaker
SQ Squelch
STBY Standby
STO Store
SWR Standing-Wave Ratio
TOT Time-Out-Timer
TX Transmit
TxD Transmit data
UHF Ultra-High Frequency
VCO Voltage-Controlled Oscillator
Vdc Volts, direct current
VHF Very-High Frequency
VOL Volume
VSWR Voltage Standing-Wave Ratio
W Watt
Ohm
°C Degrees Centigrade
°F Degrees Fahrenheit
