IC100C Series PRELIMINARY
1592015000 Manual IC100C Series 28/05/03 Page 38 di 38
38. TECHNICAL DATA
Housing: Self extinguishing ABS.
Case: Front panel 32x74 mm, depth 60mm (“C” format);
Front panel 38x185 mm; depth 75mm (“L” format)
Mounting : “C” format panel mounting in a 29x71 mm panel cut-out
“L” format panel mounting in a 150x31 mm panel cut-out with two
screws.
∅ 3 x 2mm. Distance between the holes 165mm
Protection: IP65.
Frontal protection: IP65 with frontal gasket mod RG-L or C model.
Connections: Removable terminal block 12 and 14 ways;
Power supply: 12Vac/dc
± 10%, 24Vac/dc ± 10%, 50-60Hz.
Power absorption: 5VA max.
Display: 3 digits red led and 4 digit orange led.
Inputs: 4 NTC probes,or 3 NTC probes and one 4..20mA.
Digital inputs: 5 free voltage
Relay outputs: 5 relay SPDT 8(3)A, 250Vac
Open collector: alarm output: 12V, 40mA.
Analogue output: 4..20mA for fan control, trigger for fan control
Serial output : TTL standard Communication protocol: Modbus – RTU
Data storing: on the non-volatile memory (EEPROM).
Kind of action: 1B.
Pollution grade: normal
Software class: A.
Operating temperature: 0÷60 °C.
Storage temperature: -25÷60 °C.
Relative humidity: 20
÷85% (no condensing)
Measuring range: NTC probe: -40÷110°C.
Resolution: 0,1 °C or 1°C.
Accuracy (ambient temp. 25°C): ±0,5 °C ±1 digit
Dixell s.r.l. Z.I. Via dell’Industria, 27
32010 Pieve d’Alpago (BL) ITALY
tel. +39 - 0437 - 98 33 - fax +39 - 0437 - 98 93 13
E-mail:dixell@dixell.com - http://www.dixell.com
