INSTALLATION & SETUP
17
Override
This function is used to allow a key switch to override some of the settings stored for normal operations.
When enabled and the override switch is in the closed position, the controller will override “Free Vend”,
disable vending, disable currency acceptance, display will show “No Sales”, and lights will be off. Vender
will remain in this idle state until the override switch is in the open position.
Press select button 1 and the display will show the current setting for 2 seconds (On or Off).
Press and hold select button 1 to toggle between “On” – enabled and “Off” – disabled.
Release the select button showing the setting you wish to use and display will return to “Override”.
Press select buttons 1 & 2 to scroll to “Sales Message”.
Sales Message
This function is used to turn on the scrolling message “Ice Cold Pepsi”.
Press select button 1 and the display will show the current setting (On or Off).
Press and hold select button 1 to toggle between “ On or Off”.
Release the select button showing the setting you wish to use and display will return to “Sales Message”.
Press select buttons 1 & 2 simultaneously to scroll to “Recharge”
Recharge
This function is used to enable the recharge card setting routine.
Press select button 1 and the display will show the current setting (On- recharge card enabled or Off-
recharge card disabled). Press and hold select button 1 to toggle between “On and Off”.
Release the select button showing the setting you wish to use and display will return to “Recharge”.
Press select buttons 1 & 2 simultaneously to scroll “Return”
Return
Press select button 1 to return to “User Menu”.
Press & hold select buttons 1 & 2 simultaneously to move to the next item on the menu.
Diagnostics
This function allows you to systematically diagnose problems related to the vender. To move to “Auto Test” press
select buttons 1 & 2 simultaneously, to enter sub-menu press select button 1. The following are sub-menus of
Diagnostics Menu: “Selection”, “Sold Out Empty Test”, “Sold Out Full Test”, “Motors”, “Coin mech”, “Note
Acceptor”, “Display”, “Relay”, and “Return”.
Selection
Press any select button, and the display will indicate the number of the select button pressed.
Press & hold select buttons 1 & 2 simultaneously to the next item on the menu.
Sold Out Empty Test
Use this to test the sold-out switches if the vender is empty. Press select button 1 to display any sold out
paddles that are not pressed, indicating that a column is empty. The display will automatically scroll
through the columns that are sold out. Press select button 1 to return to “Sold Out Empty Test”.
Press & hold select buttons 1 & 2 simultaneously to move to the next item on the menu.
Sold Out Full Test
Use this to test the sold out switches if the vender is full. Press select button 1 to display any Sold Out
Paddles that are pressed, indicating that the column is full. The display will scroll through the columns
that have product. Press select button 1 to return to “Sold Out Full Test”.
Press & hold select buttons 1 & 2 simultaneously to move to the next item on the menu.
