TROUBLESHOOTING FLOWCHARTS
28
These charts are intended to isolate and correct most problems you might encounter.
ALL COINS ARE REJECTED
All coins are rejected.
Main Power
Disconnected.
Apply power
Blown Fuse
Check fuses and
replace if
necessary.
Loose connection.
Check cable at
coin mech and
controller board.
Jammed coin
mechanism.
Clear coins.
Weak springs on
changer gate.
Replace spring.
Acceptor gate partially
open.
Clean and reset
acceptor gate.
Dirty / faulty coin sensor. Clean / Replace.
Incompatible coin
mechanism.
Replace with
approved coin
mechanism.
Defective coin
mechanism.
Replace with
known good
coin mechanism.
HT2 defective Universal
controller board or
HT3 Control Board.
Replace.
Check Prices Reset Price
Check mech in
diagnostics
"Coin Mech".
Check reject
button / lever for
proper
adjustment.
