PARTS LIST
NA = Not Applicable
Part numbers subject to change without notice.
84
WASHERS, BOLTS, & MISC. HARDWARE
ITEM PART NUMBER PART NAME AND DESCRIPTION
I5 901,901,89x.x1 Clamp, Cable 1" Heyco 3390
I6 900,901,79x.x1 Clamp, Nylon 5/16" Black Heyco 3355 or Dennison 10159
I7 900,901,80x.x1 Clamp, Nylon 1/2" Heyco 3328
I8 901,901,06x.x1 Hand Tie, x.x"
I9 901,902,01x.x1 Wire Tie, 7 1/2"
I10 901,901,00x.x1 Wire Ties, 4"
I11 901,900,55x.x1 Clamp, Nylon 3/4" Heyco 3382BL
I12 901,902,83x.x1 Cable Tie, x.x"
I13 900,902,14x.x1 Canoe Clip #254-090-301-00-0108
ELECTRONICS & COMPONENTS
ITEM
PART NAME AND DESCRIPTION HT2 (501E)
HT3 (501E)
1 Electronic Lock Assembly 805,202,44x.x1 805,202,44x.x1
2 Electronic Lock Light Pipe 801,814,19x.x1 801,814,19x.x1
3 Machine Controller 804,918,15x.x1 NA
4 Machine Controller Base 801,813,45x.x1 NA
5 Machine Controller Cover 631,000,68x.x3 NA
6 Universal Controller 804,916,31x.x1 NA
7 Display (Vacuum Fluorescent) 804,918,69x.x1 804,918,69x.x1
8 Transformer 804,909,80x.x1 804,909,80x.x1
9 Machine Controller EPROM 804,917,61x.x1 NA
10 Universal Controller EPROM 804,916,25x.x1 NA
11 Fuse 6 Amp (F2) 804,910,93x.x1 804,910,93x.x1
12 Fuse 1.6 Amp (F1) 804,800,71x.x1 804,800,71x.x1
13 Control Board Assy. HT3 NA 631,053,30x.x3
14 HT3 Eprom Control Board NA 804,919,24x.x1
